AJS Flat Gear Lift Pads with Slide Tubes – Replacement Pair for Spring Gear Aircraft

The Aircraft Jacking Solutions Flat Gear Pads with Slide Tubes (4361-3) are the core lift pads for spring gear general aviation aircraft, ordered as a pair with zinc-plated slide tubes for use with the AJS standard floor jack base. The patented flat pad design cradles the spring gear leg, with 1/4" rubber bonded to the lift plate and nylon-lined inserts that protect the gear leg finish during lift. Calibrated hash marks on the slide tubes allow precise height adjustment and level jacking across both sides. Order as a replacement, spare, or to build a custom AJS configuration.

Key Features

• Pair of flat gear lift pads for spring steel landing gear aircraft
• Zinc-plated slide tubes with calibrated hash marks for level positioning
• 1/4" rubber bonded to lift plates, protects gear legs under load
• Nylon-lined inserts, completely paint-safe at gear leg contact
• Patented Aircraft Jacking Solutions pad design
• Lifetime warranty on structural lift components (lift pads, slide tubes, outrigger assemblies, and hydraulic jack body) to the original owner
• Compatible with AJS standard floor jack base (4361-1)
• Designed and manufactured in the USA by Coppycog Inc., Omaha, Nebraska

Specifications

• Component type: Lift pad set (pair) with slide tubes
• Pad style: Flat gear (spring gear leg cradle)
• Pad material: 1/4" rubber bonded to lift plates
• Insert: Nylon-lined (paint-safe)
• Slide tubes: Zinc-plated with calibrated hash marks
• Quantity: 2 pads + slide tubes
• Warranty: Lifetime on structural lift components (lift pads, slide tubes, outrigger assemblies, hydraulic jack body) to the original owner

Applications & Compatible Aircraft

The 4361-3 flat gear pads work with spring steel gear legs on most GA singles including Van's RV series, Sling LSA, Piper PA-28/PA-32, Beechcraft Bonanza/Musketeer, Cessna 172/182/206, Citabria, and most other spring gear aircraft. Use with the AJS 3,800 lb standard floor jack base (4361-1).
