Cessna Curved Belly Pads with Slide Tubes – Replacement Pair for Cessna Gear Removal

The Aircraft Jacking Solutions Curved Belly Pads with Slide Tubes for Cessna (4361-4) are the lift pad set that enables gear leg removal on Cessna single-engine aircraft. Curved lift plates are matched to the Cessna fuselage belly profile below the main gear box, distributing load across the airframe while the gear legs are freed. The 1/4" rubber bonded pads with nylon-lined inserts protect the Cessna airframe finish, and zinc-plated slide tubes with calibrated hash marks keep both sides at equal height. Ordered as a pair, the right replacement or add-on component for any Cessna belly pad jacking setup.

Key Features

• Pair of curved belly lift pads for Cessna single-engine fuselage belly
• Curved lift plates matched to Cessna fuselage profile, enables gear leg removal
• Zinc-plated slide tubes with calibrated hash marks
• 1/4" rubber bonded pads protect airframe skin
• Nylon-lined inserts, paint-safe at all contact points
• Lifetime warranty on structural lift components (lift pads, slide tubes, outrigger assemblies, and hydraulic jack body) to the original owner
• Compatible with AJS standard floor jack base (4361-1)
• Designed and manufactured in the USA by Coppycog Inc., Omaha, Nebraska

Specifications

• Component type: Lift pad set (pair) with slide tubes
• Pad style: Curved belly pad (Cessna fuselage profile)
• Pad material: 1/4" rubber bonded, nylon-lined inserts
• Slide tubes: Zinc-plated with calibrated hash marks
• Quantity: 2 pads + slide tubes
• Warranty: Lifetime on structural lift components (lift pads, slide tubes, outrigger assemblies, hydraulic jack body) to the original owner

Applications & Compatible Aircraft

The 4361-4 curved belly pads fit Cessna single-engine aircraft including 172, 182, and 206 variants. Use with the AJS 3,800 lb standard floor jack base (4361-1). Curved plates are specific to Cessna fuselage geometry, confirm fitment for your variant before ordering.
