Extech DM220 Mini Pocket Multimeter with NCV

The Extech DM220 is a pocket-sized digital multimeter with a built-in non-contact voltage (NCV) detector and integrated flashlight, combining essential electrical measurement capability with practical field utility in one compact package. Featuring a 4000-count backlit LCD and a dual CAT IV-600V / CAT III-1000V safety rating, one of the highest ratings available on a pocket multimeter, the DM220 is built for technicians who need reliable diagnostics in confined spaces, low-light environments, and demanding field conditions. With integrated test lead storage clips and double-molded housing for impact protection, it is purpose-designed for everyday carry in aviation, electrical, and industrial maintenance.

Key Features

• Built-in flashlight, enables safe, single-hand diagnostics in dark aircraft compartments, avionics bays, and electrical enclosures
• Non-contact AC voltage (NCV) detector with audible and visual alert for fast live-conductor identification
• 4000-count backlit LCD for clear readings in all lighting conditions
• Dual safety rating: CAT IV-600V and CAT III-1000V, covers service entrance through component-level testing
• Integrated test lead storage clips built into the housing for organized, hands-free tool management
• Double-molded housing for enhanced impact and drop resistance
• Measures AC/DC voltage, AC/DC current, resistance, frequency, duty cycle, diode, and continuity

Specifications

• DC Voltage: up to 600V
• AC Voltage: up to 600V
• DC/AC Current: measured
• Resistance: measured
• Frequency: measured
• Duty Cycle: measured
• NCV Detection: Yes (audible and visual)
• Display: 4000-count backlit LCD
• Built-In Flashlight: Yes
• Dimensions: 4.72" x 2.2" x 1.6" (120 x 55 x 40mm)
• Weight: 5.12 oz (145g)
• Safety Rating: CAT IV-600V / CAT III-1000V
• Power: 2 x AAA batteries

Applications

The DM220 pocket multimeter is an ideal compact tool for A&P mechanics, avionics technicians, and MRO electricians working in aircraft cabins, wheel wells, avionics bays, and other confined maintenance areas where space and light are limited. The built-in flashlight allows one-person diagnostics without a separate light source, and the NCV function supports safe pre-work electrical hazard checks. Its high CAT IV-600V / CAT III-1000V dual rating makes it suitable for aircraft primary electrical systems and ground support equipment, while the integrated test lead storage keeps the tool organized and ready for rapid deployment during line maintenance operations.
