Extech EX410A True RMS Manual Ranging Multimeter

The Extech EX410A is an 8-function True RMS manual ranging digital multimeter designed for professional electricians, aviation technicians, and MRO personnel who require accurate, reliable measurements with direct control over range selection. Featuring a large-digit backlit LCD display and a Type K thermocouple input for temperature measurements, the EX410A delivers the key functions needed for thorough electrical diagnostics, AC/DC voltage up to 600V, current to 10A, resistance, diode test, and continuity, in a robust, ergonomically designed handheld instrument built for daily professional use.

Key Features

• True RMS measurement for accurate AC readings on non-sinusoidal waveforms common in aircraft electrical systems and inverter-driven circuits
• 8 measurement functions: AC/DC voltage, AC/DC current, resistance, Type K temperature, diode test, and continuity
• Manual ranging gives experienced technicians precise control over measurement ranges
• Large-digit backlit LCD with 1-inch high digits for easy reading at arm's length or in low-light maintenance environments
• Type K thermocouple input for temperature measurements from -4°F to 1832°F
• Ergonomic one-hand operation design with protective holster and built-in test lead storage
• CAT III safety-rated test leads included

Specifications

• DC Voltage: up to 600V
• AC Voltage: up to 600V (True RMS)
• DC/AC Current: up to 10A
• Resistance: standard ranges
• Temperature (Type K): -4°F to 1832°F (-20°C to 1000°C)
• Display: Large-digit backlit LCD
• True RMS: Yes
• Safety Rating: CAT III
• Number of Functions: 8
• Ranging: Manual

Applications

The EX410A True RMS multimeter is a dependable choice for aviation maintenance technicians, FBO ground crews, and MRO electricians who perform voltage verification, current measurement, resistance checks, and continuity testing on aircraft electrical systems, avionics wiring, and ground support equipment. The manual ranging design supports precise diagnostics in complex wiring environments where autoranging might select an inappropriate range, while the Type K temperature input adds utility for thermal diagnostics of aircraft electrical components, motors, and electrical connectors during maintenance inspections.

Need Your Extech EX410A Calibrated?

• PJi operates an ISO/IEC 17025 Accredited Calibration Lab and provides NIST-traceable calibration for the Extech EX410A at purchase.
• Documentation satisfies FAA Part 145, ISO 9001, and AS9100 requirements.
• PJi is the one-stop source: instrument and certificate in one transaction.
