Ideal 30-503 Crimpmaster CATV Crimp Tool with F-Die

The Ideal 30-503 Crimpmaster is a ready-to-use ratchet crimp tool kit for CATV F-type connectors on RG-59 and RG-6 coaxial cable. The kit includes the 30-506 Crimpmaster frame paired with a dedicated CATV F-connector die set, making it a complete solution for cable technicians and installers working with coaxial terminations.

Key Features

• Includes Crimpmaster frame and CATV F-connector die set, no additional purchase required
• Compatible with RG-59 and RG-6 coaxial cable F-type connectors
• Full-cycle ratchet mechanism ensures a complete crimp before the tool releases, eliminates under-crimped connections
• Ratchet release lever between handles for mid-cycle access if needed
• Fine blanked high carbon steel frame with black oxide coating
• Die changes made quickly with a flat or Phillips screwdriver
• Additional Crimpmaster die sets available for expanding to other connector types

Specifications

• Compatible Cable: RG-59, RG-6 Coaxial
• Connector Type: CATV F-Type
• Included Die Set: CATV F-Connector Die Set
• Frame Material: Fine blanked high carbon steel, black oxide finish
• Termination Method: Crimp
• Warranty: Limited 1 Year

Applications

Designed for cable installers, telecom technicians, and MRO professionals who regularly terminate RG-59 and RG-6 coaxial cable with F-type connectors. The ratchet mechanism delivers consistent crimps with every cycle, reducing connection failures in installed cable infrastructure.

Ideal 30-503 Calibration

PJi operates an ISO/IEC 17025 Accredited Calibration Lab and provides NIST-traceable calibration for the Ideal 30-503 at the time of purchase — add calibration to your order at checkout. Our calibration documentation satisfies FAA Part 145 tool control requirements, ISO 9001 quality system records, and AS9100 calibration traceability requirements. For repair stations and quality-certified facilities that require documented traceability, PJi is the one-stop source: the tool and the calibration certificate in a single transaction. Calibration-only companies cannot sell you the tool. Major retailers cannot calibrate it. PJi does both.
