Standard Features:
- 68 gal (257 l) capacity
- 100 psi (6.9 bar) maximum pressure
- 14 gpm maximum flow
- 2 micron filtration (beta rating > 2000 @ 4µm per ISO 4572)
- High displacement pneumatic pump driven by self-contained nitrogen bottle
- 15 ft (4.6 m) #6 hose with 37º JIC female swivel connector and shut-off valve
- Front wheels lock with towbar in upright position
| General Information | |
|---|---|
| Part # | 06-5025-3610 |
| Manufacturer | Tronair |
| Shipping Information | |
|---|---|
| Shipping Weight | 725 lbs. |
| Shipping Dimensions | 83 x 60 x 47 in. |
| Freight NMFC | 128000 |
| Schedule B | 8413600040 |
| ECCN | EAR99 |
| Specifications | |
|---|---|
| Fluid Type | Skydrol / Hyjet |
| Height | 52 1/2 (133) in (cm) |
| Length | 73 (185) in (cm) |
| Weight | 390 (177) lb (kg) |
| Width | 50 (127) in (cm) |
Customers also viewed
Oil Transfer Pump - Attaches to 55 Gallon Drum
Fluid Service Unit - 5606 / 83282 - Max 5000 PSIG Pressure
Reservoir Service Unit
Reservoir Service Unit
Skydrol Reservoir Service Unit - 68 Gallons - 200 PSI
AIRCRAFT COMPATIBILITY
| Compatible Aircraft* | |
|---|---|
| Airbus | A220-100 (CS100) , A220-300 (CS300) , A300 , A310 , A318 , A319 , A320 , A321 , A330-200 , A330-300 , A340-200 , A340-500 , A340-600 , A350 , A380 |
| Boeing | 707 , 727-100 , 727-200 , 737-100 , 737-200 , 737-300 , 737-400 , 737-500 , 737-600 , 737-700 , 737-800 , 737-900 , 737-BBJ , 737-BBJ2 , 747 , 757 , 767 , 777 , 787 , DC-8 Series 60 , DC-9 Series 10 , DC-9 Series 30 |
*This list is for general reference only and may not be entirely accurate for all aircraft. Please confirm all equipment meets the requirements of your aircraft with the owners/maintenance manuals prior to purchasing or using with your aircraft.
