Fluke T6-1000PRO Electrical Tester - Fluke-T6-1000PRO

The Fluke T6-1000PRO Electrical Tester with FieldSense is a slim-body instrument that measures AC voltage without touching live conductors, FieldSense technology reads voltage through the clamp body when the clamp is placed around an insulated wire, eliminating the test lead contact step entirely for voltage measurements on insulated conductors. For electricians who frequently need to verify voltage presence on live conductors before contact, the T6-1000PRO's FieldSense function reduces the number of times test leads need to make contact with energized conductors, reducing arc flash exposure per measurement and speeding up the verification workflow.

Key Features

• FieldSense Non-Contact Voltage Measurement: Place the clamp around any insulated conductor and the T6-1000PRO measures AC voltage without test lead contact to the conductor, reading through the insulation using the clamp body as the sensing element. Voltage measurement happens by proximity rather than by contact, which means faster measurements, no exposed test lead tips near live conductors, and reduced arc flash exposure per measurement cycle.
• 1000V AC/DC Voltage Range: Covers all standard industrial distribution voltages including 120V, 208V, 240V, 277V, 480V, and higher voltage industrial systems with continuous duty measurement.
• Current Measurement Through Jaws, 100A AC: Non-contact AC current measurement through the tester's built-in jaws without a separate clamp meter, up to 100A AC for branch circuit and motor running current verification alongside voltage measurement.
• Continuity Testing with Audible Beep: Circuit continuity confirmation for de-energized conductor identification, bonding verification, and wiring harness checks, the fastest confirmation that a circuit is properly connected or disconnected.
• Slim Body Design: The T5/T6 series are narrower and lighter than any clamp meter in the Fluke line, designed to fit in a shirt pocket and reach into crowded panel interiors where a full clamp meter body wouldn't fit between conductors.
• CAT III 1000V / CAT IV 600V Safety Rating.

Technical Specifications Overview

The T6-1000PRO measures AC voltage to 1000V, DC voltage to 1000V, AC current to 100A through the built-in jaws, and resistance/continuity. FieldSense technology enables voltage measurement without test lead contact on insulated conductors. It is lighter and more compact than any Fluke clamp meter, the right instrument when voltage presence verification and basic current measurement are the task, not full current range measurement or data logging.

Electrical Maintenance Applications

• Quick voltage verification on insulated conductors with FieldSense, clamp and read without lead placement
• Branch circuit current measurement during load assessment on residential and commercial panels
• Motor running current verification against nameplate FLA for HVAC and process equipment
• LOTO verification, FieldSense confirms de-energization by voltage absence without contact

Fluke T6-1000PRO Calibration

PJi operates an ISO/IEC 17025 Accredited Calibration Lab and provides NIST-traceable calibration for the Fluke T6-1000PRO at time of purchase, add calibration at checkout. Calibration documentation satisfies FAA Part 145 tool control requirements, ISO 9001 quality system records, and AS9100 traceability requirements. PJi is the one-stop source: instrument and calibration certificate in a single transaction. Amazon, Grainger, and Test Equipment Depot sell Fluke but cannot calibrate it. PJi does both.

Why Buy from Pilot John International

Pilot John International is an authorized Fluke distributor serving aviation maintenance, FAA Part 145 repair stations, and industrial MRO facilities. Our in-house ISO/IEC 17025 Accredited Calibration Lab calibrates your instrument at purchase, a capability no major online retailer matches. We stock the full Fluke catalog and ship same-business-day on in-stock items.
