Malabar 8817A Aircraft Axle Jack Trailer

Malabar 8817A
Malabar 8817AMalabar 8817A
Manufacturer: Malabar
Part Number: 8817A
Condition: New
✓ Worldwide shipping options available
✓ Manufacturer CofC always available at no cost after shipping
✓ Operating manuals available online for purchased equipment
Get Price & Order Now (it's quick & instant!)

Get a Quote or Ask a Question

Simply fill out the form below and you will receive a quote via email shortly.
Company Name:
Phone: (optional)
Questions/Comments: (optional)
Customers who viewed this item also viewed:
Towable Wheel and Brake Changer - 32 to 56 inches OD
Wheel and Brake Changer - 34 to 56 inches OD
65 Ton - "Fly-Away" Axle Jack
95 Ton Auto-Retract Axle Jack - 10.5 to 26 inches
Laser Contamination Monitor - 5606 / 83282 / 87257

The Malabar 8817A aircraft axle jack transporter virtually eliminates towing damage to axle jacks and is universal for all 45-95-ton Malabar axle jacks. Foam-filled tires are included, which eliminate flats due to punctures and provide a cushioned ride. The transporter is lightweight with rugged tubular frame construction. The balanced design means only one person is required to load and unload the axle jack

Aircraft axle jacks are frequently subjected to significant wear and tear in today’s fast-paced aircraft maintenance environment. Most axle jacks are built to withstand tow speeds up to 5 mph on smooth ramp surfaces. Excessive speed and/or uneven road or ramp surfaces accelerate wear and tear on the axle jack. Axle jack running gear components (casters, wheels, towbars and undercarriage linkage), load gauges and jack cylinder bases are often damaged beyond economical repair even during the first year of operation. Labor costs and repair parts cost can easily approach several hundred dollars per year per jack.

Standard Features

  • Manual winch for loading/unloading axle jack
  • 16-inch diameter foam-filled tires
  • Tow handle with 3-inch lunette eye for towing
  • All unpainted parts are plated to resist corrosion
  • Skydrol resistant paint (safety yellow)
  • 1-year standard warranty
  • Shipment on domestic skid


  • Unit Weight: 150 lbs (68 kg)
  • Unit Weight (with axle jack): 650 lbs (295 kg)
  • Maximum Towing Speed: 20 mph (32.2 km/h)
  • Recommended Tow Vehicle Pintle Height: 12.5 inches (318 mm) to 20.5 inches (521 mm)

For Use With

Compatible Aircraft*
AirbusA300, A310, A319, A320, A321, A330-200, A330-300, A340-200, A340-300
Boeing717, 727-100, 727-200, 737-100, 737-200, 737-300, 737-400, 737-500, 737-600, 737-700, 737-800, 737-900, 737-BBJ, 737-BBJ2, 747, 747-8, 757, 767, 777, 787
McDonnell DouglasMD-80
*This list is for general reference only and may not be entirely acurate for all aircraft. Please confirm all equipment meets the requirements of your aircraft with the owners/maintenance manuals prior to purchasing or using with your aircraft.
