Malabar PF56180 Boeing 787 Coolant Top-Off Pack

Malabar PF56180
Malabar PF56180Malabar PF56180
Manufacturer: Malabar
Part Number: PF56180
Condition: New

Get a Quote or Ask a Question

Simply fill out the form below and you will receive a quote via email shortly.
Name:
E-Mail:
Company Name:
Phone: (optional)
Questions/Comments: (optional)
Customers who viewed this item also viewed:
5 Gallon Turbine Oil Dispenser
65 Ton Axle Jack - Rhino - 4.5 inches up to 28.5 inches
DC10, Boeing 767, L-1011, A340, MD-11, A330, A350, Boeing 777
1 Quart & 1 Liter Turbine Oil O-C Gun
Fluid Service Unit (Viton) (Ce) - 6 Gallon - MIL-L-23699 or MIl-PRF-87257

The Malabar PF56180 B787 Coolant Top-Off Pack (CTOP) is designed in accordance with Boeing 787 system & equipment engineering specifications to meet the special servicing requirements of the aircraft environmental control systems (PECS, ICS, FCAC).

To facilitate connections to the various aircraft systems, a K-Tool Adapter Kit p/n K21016-129 can be obtained from us.

Standard Features

  • Towable unit with stainless steel fluid reservoirs
  • Clean fluid reservoir
  • Waste fluid reservoir
  • Manual hand pump and integral relief valve
  • Inline fluid sight gauges
  • Fluid filter
  • Delivery pressure gauge
  • Fluid level indicators
  • Fluid hoses
  • All materials are compatible with BMS3-42 fluid
  • An integrated storage enclosure for K-Tool Adapter Set K21016-129
  • 1-year standard warranty
  • Shipped in a crate

Specficiations

  • Fluid: BMS3-42 fluid
  • Clean Fluid Capacity: 6 gallons (22.7 liters)
  • Waste Fluid Capacity: 3 gallons (11.4 liters)
  • Pump Displacement per Stroke: 3 cu inches (1.7 fl oz)
  • Pump Outlet Pressure: 50-200 psig (3.5-14.1 kg/sq cm)
  • Supply/Return Hose Length (2): 240 inches (6096 mm)
  • Relief Valve Set At: 70 psig (4.9 kg/sq cm)
  • Maximum Towing Speed: 10 mph (16 km/h)
  • Approximate Dry Weight.: 100 lbs (45.4 kg)
Compatible Aircraft*
Boeing787
*This list is for general reference only and may not be entirely acurate for all aircraft. Please confirm all equipment meets the requirements of your aircraft with the owners/maintenance manuals prior to purchasing or using with your aircraft.
Shipping Information
Pkg. 1 Weight250 lbs.
Pkg. 1 Dimensions26 in. x 34 in. x 52 in.
Pkg. 1 TypeCrate
Freight Class70
