The Trig Avionics 01740-00 is a TA70 WAAS GPS Antenna that has been produced in conjunction with Trig Avionics’ partner, RAMI, to ensure optimum performance with all Trig GPS position source products.
The TA70 is a fully certified TSO-C190 antenna that’s compatible and proven with Trig transponders and supported by Trig’s free ADS-B STC program.
This future-proof product is fully compliant with the latest FAA 2020 ADS-B requirements, making it the logical choice for the majority of installations. The TA70 GPS Antenna can be paired with either the TN70 or TN72 GPS receivers.
Lightweight and easy to install, the TA70 GPS antenna comes with a superior rubber gasket feature that provides coverage of existing antenna holes, yielding a secure and weathertight seal.
Standard Features
- Optimized for use with Trig Avionics’ GPS units
- Compliant for 2020 ADS-B Out
- SBAS supports EGNOS, GAGAN, MSAS, and WAAS
- Ideal as a retro-fit antenna option
- Mounting plate, fixing screws, and installation instructions included
Specifications
- Certification: TSO-C190
- Compliance: DO-301, DO-160G
- Supply Voltage: 4.5V to 14.5V DC
- Typical Consumption (@ 14V): 40mA Typ / 60mA max.
- Operating Temperature: -55°C to 70°C (-67°F to 158°F)
- Weight: 0.31 lbs. (0.14 kg)
- Dimensions: 1.59" x 2.87" x 4.71" (4.04 x 7.29 x 11.96 cm)
| General Information | |
|---|---|
| Part # | 01740-00 |
| Manufacturer | Trig Avionics |
Customers also viewed
AIRCRAFT COMPATIBILITY
| Compatible Aircraft* |
|---|
PRODUCT REVIEWS
This item does not have any reviews yet.
QUESTIONS & ANSWERS
The TA70 antenna is included as standard in a TN70 GPS kit. This simplifies compliance, as both the GPS and antenna meet the FAA 2020 mandate for ADS-B.
However, the TA70 is not included when purchasing a TN72. This is because uncertified pilots do not need a certified antenna.
The TA70 has a screw-on TNC connector.
WAAS, short for Wide Area Augmentation System, is a satellite-based augmentation system developed by the Federal Aviation Administration (FAA) to improve the accuracy, integrity, and availability of GPS signals for aviation purposes.
The primary goal of WAAS is to enhance the precision of GPS signals, particularly in critical applications such as aircraft navigation during approach, landing, and en-route phases. WAAS achieves this by using a network of ground-based reference stations and geostationary satellites to monitor GPS signals for errors caused by factors like atmospheric conditions and satellite geometry.
The Trig TA70 GPS antenna comes with a two-year warranty, starting from the day of installation. The warranty covers repair and/or replacement, at Trig’s option, of any parts found to be defective, provided such defects are deemed due to faulty material or workmanship and are not caused by tampering, abuse, or normal wear.
The TA70 is an active (amplified) antenna providing an average of 28.5 dB gain over a passive (non-amplified) antenna.
