Parker 44004-04A-N1 Quick-Disconnect Fitting for Ground Support Equipment - Hydraulic Fluid (Red Oil

The Parker 44004-04A-N1 Quick-Disconnect Fitting is a thread-together style self-sealing coupling designed specifically for connecting ground support carts to aircraft hydraulic systems. This coupling offers reliable performance, simple one-handed operation, and positive latching to ensure secure, leak-free connections during aircraft ground maintenance. With its durable aluminum alloy anodized body, it is engineered for long-term reliability, making it an essential component in both commercial and military programs.

Key Features

• High Pressure Rating: The coupling supports a maximum operating pressure of 3000 psig and burst pressure of 7500 psig, ensuring reliable performance in hydraulic systems.
• Fluid Compatibility: Designed for use with hydraulic fluids such as Red Oil (5606/83282), making it ideal for aircraft ground support systems.
• Efficient Fluid Flow: The self-sealing valve minimizes pressure loss and turbulence while allowing fluid flow, and its flush-faced design reduces air inclusion or spillage during coupling or uncoupling.
• Positive Latching Mechanism: Features a ratchet-tooth style latching system that ensures the coupling halves are positively locked in place for added safety and security.
• Durable Construction: Constructed from anodized aluminum alloy for corrosion resistance and long-lasting performance, even in harsh environments.
• Compact Design: With a 1/4 inch inlet and 3.15-inch overall length, this coupling is perfect for installations with limited space, offering reliable, high-performance operation.

Specifications

• Part Number: 44004-04A-N1
• Line Size (Inlet): 1/4 inch
• Body Material: Aluminum Alloy Anodized
• Fluid Type: Hydraulic Fluid (Red Oil, 5606/83282)
• Maximum Operating Pressure: 3000 psig
• Minimum Operating Pressure: -5 psig
• Proof Pressure: 4500 psig
• Burst Pressure: 7500 psig
• Maximum Fluid Temperature: 275°F
• Minimum Fluid Temperature: -65°F
• Flow Rate: 1.2 gal/min
• Maximum Spill Volume at Disconnection: 0.008 cc
• Maximum Air Inclusion: 0.01 cc
• Maximum Pressure to Connect: 20 psig
• Overall Length: 3.15 inches (hex to hex)
• Outside Diameter: 1.75 inches
• Fitting Type: SAE AS4395E20
• Dust Cap Option: P44000-04-N1

Why Choose Parker 44004-04A-N1?

• Reliable Performance: Specifically designed for hydraulic ground support applications with proven reliability across military and commercial aircraft.
• Safety and Efficiency: Positive visual and tactile feedback confirms the secure connection, while the ratchet-locking mechanism ensures safety.
• Durable and Lightweight: The aluminum alloy construction provides corrosion resistance and a lightweight design for easy handling in the field.
• Simple One-Handed Operation: The coupling halves are easy to connect and disconnect with just one hand, making maintenance faster and more efficient.
• Versatile Fluid Compatibility: Compatible with a variety of hydraulic fluids, including Red Oil (5606/83282), making it a flexible solution for different ground support systems.
