Gill Aircraft Battery Cross-Reference Guide
28-Minute Read
Choosing the right aircraft battery doesn’t have to be complicated. Whether you’re performing scheduled maintenance or replacing a worn-out unit, having a reliable cross-reference chart can save valuable time. Gill aircraft batteries are trusted across general and business aviation for their durability, long service life, and FAA/PMA approvals.
In this quick reference guide, we’ll match specific aircraft makes and models with the appropriate Gill battery – whether dry-charged (flooded) lead-acid or sealed valve-regulated lead-acid (VRLA) – and provide part number equivalents from other battery brands, making it easy to upgrade with confidence. Use this guide to quickly find the recommended Gill battery for your aircraft, so you can stay flight-ready with the ideal power solution on board.
| Aircraft OEM | Aircraft Model(s) | Gill Dry-Charged | Gill Sealed VRLA | Prev. Gill Part # | Concorde Equivalent | Air Tractor Equivalent | Marathon Equivalent |
| Aerostar (Piper) | PA-60-600, PA-60-601, PA-60-601P, PA-60-602P, PA-60-700P | N/A | 7025-20 or 7025-24 | G-25M, G-25S | RG-25, RG-25XC | N/A | N/A |
| Aerostar (Piper) | 600, 601, 601P | G-25 | N/A | N/A | RG-25, RG-25XC | N/A | N/A |
| Agusta S.p.A | AB139, AW139 | N/A | 7638-44* and 7407-28 | N/A | RG-380E/40, RG-380E/44, RG-407 | N/A | 31908-001, TSP-283, 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Agusta S.p.A | A109C, A109E, A119, AW119 MKII | N/A | 7639-30LT* | N/A | RG-390E/30 | N/A | N/A |
| Air Tractor | AT-301, AT-301A | GE-51E | N/A | N/A | N/A | N/A | N/A |
| Air Tractor | AT-300, AT-302, AT-400, AT-400A, AT-402, AT-402A, AT-402B, AT-502, AT-502A, AT-502B, AT-503A, AT-602, AT-802, AT-802A | G-246 | N/A | N/A | RG24-20 | 7246-20AT, G-246AT | N/A |
| Air Tractor | AT-402, AT402A, AT402B, AT502, AT-502A, AT-502B, AT-602, AT-802, AT-802A | G-246 | 7246-20 | PS12-24P11 | RG24-20 | 7246-20AT, G-246AT | 27662-021, 29365-01C, 30135-001, 30135-002, 30450-01, 30554-01C, 32007-001, 32749-001, 32752-001, CA 103, CA 1700, CA 170A, M3-1700L, M3-170AL, SP 1700, SP 170A, SP 170AL, SP1700L |
| Airbus Helicopters (Eurocopter) | AS350B, AS350B1, AS350B2, AS350B3, AS350BA, AS350C, AS350D, AS350D1 | N/A | 7641-20 | N/A | RG-206, RG-350, RG-355 | N/A | N/A |
| Airbus Helicopters (Eurocopter) | EC135P1, EC135P2, EC135P2+, EC135T1, EC135T2, EC135T2+ | N/A | 7638-44* | N/A | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Aircraft OEM | Aircraft Model(s) | Gill Dry-Charged | Gill Sealed VRLA | Prev. Gill Part # | Concorde Equivalent | Air Tractor Equivalent | Marathon Equivalent |
| Airbus Helicopters (Eurocopter) | MBB-BK117 C-2 | N/A | 7638-44* | N/A | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Airbus Helicopters (Eurocopter) | BO-105S | G-639E* | N/A | N/A | RG-390E/30 | N/A | N/A |
| Airbus Helicopters (Eurocopter) | B0-105A, B0-105C, B0-105S, MBB-BK117 A-1, -BK117 A-3, -BK117 A-4, -BK117 B-1, -BK117 B-2, -BK117 C-1 | N/A | 7639-27 | G-639ES | RG-390E | N/A | N/A |
| Alexandria Aircraft (Bellanca) | 17-30, 17-30A, 17-31, 17-31A, 17-31TC, 17-31ATC | N/A | 7035-28 or 7035-34 | G-35S | RG-35, RG-35A, RG-35AXC | N/A | N/A |
| American Champion | 7ACA, 7ECA, 7GCBC | N/A | 7025-20 or 7025-24 | PS6-9 | RG-25, RG-25XC | N/A | N/A |
| American Champion | 7GCAA, 7GCBC, 7KCAB, 8KCAB | N/A | 7035-28 or 7035-34 | G-35S | RG-35, RG-35A, RG-35AXC | N/A | N/A |
| ATR | ATR42-200, ATR42-300, ATR42-320, ATR42-500, ATR72-101, ATR72-102, ATR72-201, ATR72-202, ATR72-211, ATR72-212, ATR72-212A | N/A | 7638-44* and 7641-20 | N/A | RG-380E/40, RG-380E/44, RG-206, RG-350, RG-355 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Ayers | S-2R | G-88 | N/A | N/A | N/A | N/A | N/A |
| Beechcraft | 17, 18, 19, 23, 24, 33, 35, 36, 50, 76 | G-35 | N/A | N/A | RG-35, RG-35A, RG-35AXC | N/A | N/A |
| Aircraft OEM | Aircraft Model(s) | Gill Dry-Charged | Gill Sealed VRLA | Prev. Gill Part # | Concorde Equivalent | Air Tractor Equivalent | Marathon Equivalent |
| Beechcraft | 19, 23, 24, 55, 58, 77 | G-25 | N/A | PS6-9 | RG-25, RG-25XC | N/A | N/A |
| Beechcraft | 65, A65, 65-80, 65-A80, 65-B80, 65-88, 70 | G-640E** | N/A | N/A | N/A | N/A | N/A |
| Beechcraft | 65-90, 65-A90, 65-A90-1, (JU-21A, U-21A, RU-21A, RU-21D, U-21G, RU-21H), 65-A90-4(RU-21E, RU-21H), B90, C90, C90A (S/N 1085 through 1533), E90, 99, A100 | G-6381E* | N/A | G6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Beechcraft | 65-90, 65-A90, 65-A90-1, (JU-21A, U-21A, RU-21A, RU-21D, U-21G, RU-21H), 65-A90-4(RU-21E, RU-21H), B90, C90, E90, 99, A100 | 7000 Series by PMA | 7638-44* | G6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Beechcraft | 99, 99A, A99A, 100, A100, A100A | G-6381E* | N/A | BB638/T | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Beechcraft | A100 | G-6381E* | N/A | BB638/T | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Beechcraft | A60 | G-244 | N/A | N/A | RG24-20 | 7246-20AT, G-246AT | 27662-021, 29365-01C, 30135-001, 30135-002, 30450-001, 30554-01C, 32007-001, 32749-001, 32752-001, CA 103, CA 1700, CA 170A, M3-1700L, M3-170AL, SP 1700, SP 170A, SP 170AL, SP1700L |
| Beechcraft | B100 | G-6381E* | N/A | BB638/T | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Beechcraft | C90, E90, B99, F90 | G-6381E* | N/A | BB638/T | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Aircraft OEM | Aircraft Model(s) | Gill Dry-Charged | Gill Sealed VRLA | Prev. Gill Part # | Concorde Equivalent | Air Tractor Equivalent | Marathon Equivalent |
| Beechcraft | DH.125 Series 400, HS.125 Series 600, HS. 125 Series 700, BH.125 Series 600, BAe 125 Series 800 | N/A | 7639-27 | G-639ES | RG-390E | N/A | N/A |
| Beechcraft | 99, 99A, A99, A99A, 100, A100, A100A, B90, C90, E90, F90, 65-90, 65-A90 | G-6381E* | N/A | N/A | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Beechcraft | 3000 | N/A | 7638-44ST | N/A | N/A | N/A | N/A |
| Beechcraft | 200, (A100-1 U-21), 200C, 200CT, 200T, A200 (C-12A) or (C-12C), A200CT(C-12D) or (FWC-12D) or (RC-12D) or (C-12F) or (RC-12G) or (RC-12H) or (RC-12K) or (RC-12P), B200, B200C, (C-12F) or (UC-12F) or (UC-12M) or (C-12R), B200CT, B200T, 300, B300, 300LW, B300C | G-6381E* | N/A | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Beechcraft | 65-90, 65-A90, 65-A90-1(JU-21A) or (U-21A) or (RU-21A) or (RU-21D) or (U-21G) or (RU-21H), 65-A90-4(RU-21E) or (RU-21H), B90, B99, C90, E90, F90, 99, 99A, A100(U-21F), A100A, B100, 200(A100-1(U-21J), 300, 200, 200C, 200CT, 200T, A200(C-12A) or (C-12C), A200CT(C-12D) or (FWC-12D) or (RC-12D) or (C-12F) or (RC-12G) or (RG-12H) or (RC-12K), or (RC-12P), B200, B200C (C-12F), or (UC-12F) or (UC-12M) or (C-12R), B200CT, B200T, B300, 300LW, B300, B300C, 400A (S/N #RK-98 and after), MU-300-10, 400, 400T, Hawker 1000 | N/A | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Beechcraft | C23, C24R, F33C, V35B, A36, G36, D55, D55A, E55, E55A, 58TC, 58TCA, 76, 95-55, 95-A55, 95-B55, 95-B55A | N/A | 7242-14 | N/A | RG24-10, RG24-11, RG24-11M, RG24-15 | N/A | N/A |
| Beechcraft | 19A, B19, M19A, 23, A23, A23A, A23-19, A23-24, B23, C23, A24, A24R, B24R, C24R, E33, E33A, F33, F33A, F33C, G33, 35, 35-33, 35-A33, 35-B33, 35-C33, 35-C33A, A35, B35, C35, D35, E35, F35, G35, H35, J35, K35, M35, N35, P35, S35, V35, V35A, V35B, 36, A36, A36TC, B36TC, G36, 76 | N/A | 7035-28 or 7035-34 | G-35S | RG-35, RG-35A, RG-35AXC | N/A | N/A |
| Beechcraft | Hawker 1000 | G-6381E* | N/A | N/A | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Beechcraft | 19A, B19, 23, A23, A23A, B23, C23, A24, A24R, B24R, C24R, E33, E33A, E33C, F33, G33, 35-33, 35-A33, 35-B33, 35-C33, 35-C33A, D55, D55A, E55, E55A, 58, 58A, 58P, 58TC, G58, 77, 95, B95, B95A, D95A, E95, 95-55, 95-A55, 95-B55, 95-C55, 95-C55A | N/A | 7025-20 or 7025-24 | N/A | RG-25, RG-25XC | N/A | N/A |
| Aircraft OEM | Aircraft Model(s) | Gill Dry-Charged | Gill Sealed VRLA | Prev. Gill Part # | Concorde Equivalent | Air Tractor Equivalent | Marathon Equivalent |
| Beechcraft | 1900C, 1900D | N/A | 7638-44* | N/A | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Bell | 204B, 205A, 205A-1 | G-6381E* | N/A | N/A | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Bell | 206, 206A, 206B, 206B-1, 206L, 206L- 1, 206L-3 | G-641 | N/A | N/A | RG-206, RG-350, RG-355 | N/A | N/A |
| Bell | 206A, 206B, 206L, 206L-1, 206L-3, 206L-4 | G-641 | 7641-20 | G-641S | RG-206, RG-350, RG-355 | N/A | N/A |
| Bell | 212, 412 | G-6381E* | N/A | BB638/T | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Bell | 222U | G-6381E* | N/A | N/A | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Bell | 47G-5 | G-35 | N/A | N/A | RG-35, RG-35A, RG-35AXC | N/A | N/A |
| Bell | 407 | N/A | 7407-28 | N/A | RG-407 | N/A | 31908-001, TSP-283 |
| Bell | 429 | N/A | 7639-25 and 7638-53 | N/A | RG-390E/25, RG-380E/53L | N/A | N/A |
| Aircraft OEM | Aircraft Model(s) | Gill Dry-Charged | Gill Sealed VRLA | Prev. Gill Part # | Concorde Equivalent | Air Tractor Equivalent | Marathon Equivalent |
| Bell | 204B, 205A, 205A-1, 205B, 212, 222U, 412, 412EP | 7000 Series by PMA | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Bell | 212, 412, 412EP (with STC SH1186SO Installed) | N/A | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Bombardier | DHC-8-100 Series, DHC-8-200 Series, DHC-8-300 Series | 7000 Series by PMA | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| British Aerospace | DH.125-400A, HS.125-600A, HS.125-700A, BH.125-600A, BAe.125-800A | G-639E* | N/A | N/A | RG-390E/30 | N/A | N/A |
| British Aerospace | Jetstream 3101 Series | G-639E* | 7639-27 | G-639ES | RG-390E/30, RG-390E | N/A | N/A |
| Cessna | 425 | G-6381E* | N/A | N/A | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Cessna | 650 Series | N/A | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Cessna | 120, 140, 150, 170, 172, 175, 177, 310, 320, 340 | G-25 | N/A | N/A | RG-25, RG-25XC | N/A | N/A |
| Cessna | 120, 140, 150, 150A, 150B, 150C, 150D, 150E, 150F, 150G, 150H, 150J, 150K, 150L, 150M, A150K, A150L, A150M, 170, 172, 172B, 172C, 172D, 172E, 172F (USAF T-41A), 172G, 172H (USAF T-41A), 172I, 172K, 172L, 172M, 172N, F172D, F172E, F172F, F172G, F172H, F172K, F172L, F172M, F172N, 175, 175B, 175C, P172D, 177, 177A, 177B, 188, 188A, 188B, T188C, 310, 310B, 310C, 310D, 310F, 310G, 310H, E310H, 310I, 310J, 310J-1, E310J, 310K, 310P, 310Q, 320, 340 | N/A | 7025-20 or 7025-24 | G-25S, PS6-9 | RG-25, RG-25XC | N/A | N/A |
| Aircraft OEM | Aircraft Model(s) | Gill Dry-Charged | Gill Sealed VRLA | Prev. Gill Part # | Concorde Equivalent | Air Tractor Equivalent | Marathon Equivalent |
| Cessna | 152, 172, 182 | G-242 | N/A | G-240 | RG24-10, RG24-11, RG24-11M, RG24-15 | N/A | N/A |
| Cessna | 152, 172, 172R, 172S, 182 | G-243 | N/A | G-241 | RG24-16, RG24-17 | N/A | N/A |
| Cessna | 152, 172, 177, 182, 207, 210, 336, 337 | G-242 | N/A | G-242S | RG24-10, RG24-11, RG24-11M, RG24-15 | N/A | N/A |
| Cessna | A152, 172, 172R, 172RG, R182, T182, TR182, 188, 188A, 188B, A188, A188A, A188B and T188C, 210 (S/N 21059503 & ON), T210M, T210N, T210R, T303 | G-243 | N/A | N/A | RG24-16, RG24-17 | N/A | N/A |
| Cessna | 152, A152, 172N, 172P, 172Q, 172R, 172RG, 172S, F172N, F172P, FR172K, R172K, 182S, 182T, R182, T182, T182T, TR182, A188B, P210N, T303, 182 | N/A | 7243-16 | G-243S | RG24-16, RG24-17 | N/A | N/A |
| Cessna | 177, 177A, 177B, 180A, 180B, 180C, 180D, 180E, 180F, 180G, 180H, 180J, 180K, 182A, 182B, 182C, 182D, 182E, 182F, 182G, 182H, 182J, 182K, 182L, 182M, 182N, 182P, 182Q, 185, 185A, 185B, 185C, 185D, 185E, A185E, A185F, A188A, A188B, 190, 195, 195A, 195B, 206, P206, P206A, P206B, P206C, P206D, P206E, U206, U206A, U206B, U206C, U206D, U206E, U206F, U206G, 207, 207A, T207, T207A, 210, 210B, 210C, 210D, 210E, 210F, 210G, 210H, 210J, 210K, T210F, T210G, T210H, T210J, T210K, T210L, T210M , T210N, T210R | N/A | 7035-28 or 7035-34 | G-35S | RG-35, RG-35A, RG-35AXC | N/A | N/A |
| Cessna | 180, 182, 185, 188, 195, 206, 207, 210 Series | G-35 | N/A | N/A | RG-35, RG-35A, RG-35AXC | N/A | N/A |
| Cessna | 208, 208A, 208B | 7000 Series by PMA | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Cessna | 208, 208B | G-6381E* | N/A | N/A | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Aircraft OEM | Aircraft Model(s) | Gill Dry-Charged | Gill Sealed VRLA | Prev. Gill Part # | Concorde Equivalent | Air Tractor Equivalent | Marathon Equivalent |
| Cessna | 310, 335, 340, 402, 404, 414, 421 | G-244 | N/A | PS12-24P9 | RG24-20 | 7246-20AT, G-246AT | 27662-021, 29365-01C, 30135-001, 30135-002, 30450-001, 30554-01C, 32007-001, 32749-001, 32752-001, CA 103, CA 1700, CA 170A, M3-1700L, M3-170AL, SP 1700, SP 170A, SP 170AL, SP1700L |
| Cessna | 310R, T310R, 404 | N/A | 7246-20 | N/A | RG24-20 | 7246-20AT, G-246AT | 27662-021, 29365-01C, 30135-001, 30135-002, 30450-001, 30554-01C, 32007-001, 32749-001, 32752-001, CA 103, CA 1700, CA 170A, M3-1700L, M3-170AL, SP 1700, SP 170A, SP 170AL, SP1700L |
| Cessna | 500, 501, 550, S-550, 551, 560 | G-6381E* | N/A | BB638/T | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Cessna | 510 | N/A | 7639-30LT* | N/A | RG-390E/30 | N/A | N/A |
| Cessna | 152, A152, F152, FA152, 172N, 172P, 172Q, 172R, 172RG, 172S, F172N, F172P, FR172K, R172K, 182Q, 182R, 182S, 182T, F182Q, R182, T182, T182T, TR182, A188B, T303 | N/A | 7243-14 | G243S | RG24-16 | N/A | N/A |
| Cessna | 152, A152, 172N, R172K, 177B, 177RG, 180K 182Q, F182Q, R182, A185F, A188B, T188C, T206H, TU206G, U206G, 207A, T207A,210M, 210N, 210R, P210N, T210M, T210N, T210R, 337H, FT337HP, P337H, T337H, T337H-SP, F152, FA152, F172N, FR172K, FR182 | N/A | 7242-14 | N/A | RG24-10, RG24-11, RG24-11M, RG24-15 | N/A | N/A |
| Cessna | 650 Series | 7000 Series by PMA | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Cessna | 425, 441, 500, 501, 550, S550, 551, 560, 560XL | N/A | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Cessna | 525/525A Series | 7000 Series by PMA | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Aircraft OEM | Aircraft Model(s) | Gill Dry-Charged | Gill Sealed VRLA | Prev. Gill Part # | Concorde Equivalent | Air Tractor Equivalent | Marathon Equivalent |
| Cessna | 525, 525A, 525B, 525C | N/A | 7638-44T | N/A | RG-380E/40B | N/A | 24535-015, 30665-002, 30978-002, 31169-001, 32663-001, ATSP 280, ATSP 400-2, ATSP 44, CA 5H, M3-44-1 |
| Cessna | 500, 501, 550, 551, S550, 560, 560XL, 650, 680, 750 | N/A | 7638-44T | N/A | RG-380E/40B | N/A | 24535-015, 30665-002, 30978-002, 31169-001, 32663-001, ATSP 280, ATSP 400-2, ATSP 44, CA 5H, M3-44-1 |
| Cirrus | SR20, SR22 | G-243 | N/A | N/A | RG24-16, RG24-17 | N/A | N/A |
| Cirrus | SR20, SR22, SR22T | N/A | 7243-14 or 7243-16 | G243S | RG24-16, RG24-17 | N/A | N/A |
| Commander (Rockwell) | 112, 112TC, 112B, 112TCA | N/A | 7025-20 or 7025-24 | G-25S, PS6-9 | RG-25, RG-25XC | N/A | N/A |
| Commander (Rockwell) | 114B, 114TC | N/A | 7243-14 | N/A | RG24-16 | N/A | N/A |
| CPAC, Inc. (Commander Aircraft Corp.) | 112, 112B, 112TC, 112TCA, 114, 114A | N/A | 7035-28 or 7035-34 | G-35S | RG-35, RG-35A, RG-35AXC | N/A | N/A |
| CPAC, Inc. (Commander Aircraft Corp.) | 114B, 114TC | N/A | 7243-16 | G243S | RG24-16, RG24-17 | N/A | N/A |
| Dassault | Fan Jet Falcon Series C, D, E, F | G-6381E* | N/A | G-6381C | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Aircraft OEM | Aircraft Model(s) | Gill Dry-Charged | Gill Sealed VRLA | Prev. Gill Part # | Concorde Equivalent | Air Tractor Equivalent | Marathon Equivalent |
| Dassault | Falcon 10 | N/A | 7639-27 | G-639ES | RG-390E | N/A | N/A |
| Dassault | Fan Jet Falcon Series C, D, E, F | N/A | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Diamond | DA 40, DA 42 | N/A | 7243-14 or 7243-16 | G243S | RG24-16, RG24-17 | N/A | N/A |
| Embraer | EMB-110P1, EMB-110P2 | G-6381E* | N/A | BB638/T | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Embraer | EMB-500 | N/A | 7639-30LT* or 7639-27 | N/A | RG-390E/30, RG-390E | N/A | N/A |
| Embraer | EMB-505 | N/A | 7638-36 | N/A | N/A | N/A | N/A |
| Embraer | EMB-505 | N/A | 7639-34 or 7638-48P | N/A | N/A | N/A | N/A |
| Embraer | EMB-110P1, EMB-110P2 | G-6381E* | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Enstrom | TH-28, 480, 480B | G-641 | 7641-20 | N/A | RG-206, RG-350, RG-355 | N/A | N/A |
| Aircraft OEM | Aircraft Model(s) | Gill Dry-Charged | Gill Sealed VRLA | Prev. Gill Part # | Concorde Equivalent | Air Tractor Equivalent | Marathon Equivalent |
| Globe (Swift) | GC-1A, GC-1B | N/A | 7035-28 | G-35S | RG-35, RG-35A | N/A | N/A |
| Gulfstream Aerospace | G-159 | G-6381E* | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Gulfstream Aerospace | G-159, G-1159 | 7000 Series by PMA | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Gulfstream Aerospace | G280 (Licensing Agreement) | N/A | 7638-38HT | N/A | N/A | N/A | N/A |
| Gulfstream Commander | 500, 520, 560, 560A, 560E, 680, 680E, 720 | GE-50E | N/A | N/A | N/A | N/A | N/A |
| Israel Aircraft Industries (IAI) | 1121, 1121A, 1121B, 1123, 1124 | N/A | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Israel Aircraft Industries (IAI) | 1121, 1121A, 1121B (Aero Commander) | G-6381E* | N/A | N/A | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Israel Aircraft Industries (IAI) | 1123, 1124 (Westwind) | G-6381E* | N/A | N/A | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Learjet | 23, 24 Series, 25 Series, 28 Series, 29 Series, 35 Series, 36 Series | G-6381E* | N/A | BB638/T | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Aircraft OEM | Aircraft Model(s) | Gill Dry-Charged | Gill Sealed VRLA | Prev. Gill Part # | Concorde Equivalent | Air Tractor Equivalent | Marathon Equivalent |
| Learjet | 23, 24, 24A, 24B, 24B-A, 24C, 24D, 24D-A, 24E, 24F, 24F-A, 25, 25B, 25C, 25D, 25F | G-6381E* | N/A | N/A | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Learjet | 24, Starting With S/N 210, 25, S/N 040, 046 and Subsequent, all 28, 35 Series Originally Equipped with Ni-Cd with Thermal Switches | G-6381E* | N/A | N/A | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Learjet | Used with G.L.C. Service Bulletins 24/25-334A, 28/29-24-5A and 35/36-24-10 for Models: 24-357, 25-059, 25-060, 25-061, 25-066 Thru 25-373, 28-001 Thru 28-005, 29-001 Thru 29-004, 35-001 Thru 35-570, 35-589 Thru 35-600, 36-001 Thru 36-053 and 35-055 |
G-6381E* | N/A | N/A | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Learjet | 31, 31A, 55, 55B, 55C | G-6381E* | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Learjet | 60 | N/A | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Learjet | 23, 24, 24A, 24B, 24B-A, 24C, 24D, 24D-A, 24E, 24F, 24F-A, 25, 25A, 25B, 25C, 25D, 25F, 28, 29, 35, 35A, 36A | N/A | 7638-44* | N/A | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Lockheed-Georgia | 1329-23A, 1329-23D, 1329-23E | N/A | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Lockheed-Georgia | 1329-23 Series | N/A | 7638-44* | N/A | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Maule | M-4-180C, M-4-210, M-4-210C, M-4-230C, M-5-180C, M-5-200, M-5-210C, M-5-220C, M-5-235C, M-6-180, M-6-235, M-7-235, MX-7-180, MX-7-235 | G-35M** | N/A | N/A | N/A | N/A | N/A |
| Aircraft OEM | Aircraft Model(s) | Gill Dry-Charged | Gill Sealed VRLA | Prev. Gill Part # | Concorde Equivalent | Air Tractor Equivalent | Marathon Equivalent |
| Maule | M-4-180V, M-5-180C, M-5-235C, M-6-180, M-6-235, M-7-235, M-7-235A, M-7-235B, M-7-235C, M-7-260, M-7-260C, M-8-235, MT-7-235, MT-7-260, MX-7-160, MX-7-160C, MX-7-180, MX-7-180A, MX-7-180AC, MX-7-180B, MX-7-180C, MX-7-235, MXT-7-160, MXT-7-180, MXT-7-180A | N/A | 7243-16 | G243S | RG24-16, RG24-17 | N/A | N/A |
| Maule | M-4-180V, M-5-180C, M-5-235C, M-6-180, M-6-235, M-7-235, M-7-235A, M-7-235B, M-7-235C, M-7-260, M-7-260C, M-8-235, MT-7-235, MT-7-260, MX-7-160, MX-7-160C, MX-7-180, MX-7-180A, MX-7-180B, MX-7-180C, MX-7-180 AC, MXT-7-160, MXT-7-180, MXT-7-180A | N/A | 7035-28 or 7035-34 | G-35S | RG-35, RG-35A, RG-35AXC | N/A | N/A |
| Maule | M-4-180V, M-6-180, M-6-235, M-7-235, M-7-235A, M-7-235B, M-7-235C, M-7-260, M-7-260C, M-7-420A, M-7-420AC, MT-7-235, MT-7-260, MT-7-420, MX-7-160, MX-7-160C, MX-7-180, MX-7-180A, MX-7-180AC, MX-7-180B, MX-7-180C, MX-7-235, MXT-7-160, MXT-7-180, MXT-7-180A, M-8-235 | G-243 | 7243-14 | G243S | RG24-16 | N/A | N/A |
| MD Helicopters | 369, 369A, 369D, 369E, 369F, 369FF, 369H, 369HE, 369HM, 369HS, 500N, 600N | G-641 | N/A | G-641S | RG-206, RG-350, RG-355 | N/A | N/A |
| MD Helicopters | 369, 369A, 369D, 369E, 369F, 369FF, 369H, 369HE, 369HM, 369HS, 500N, 600N | 7000 Series by PMA | 7641-20 | G-641S | RG-206, RG-350, RG-355 | N/A | N/A |
| Mitsubishi | MU-2B, MU-2B-10, -15, -20, -25, -26, -26A, -30, -35, -36, -36A, -40, -60 | G-6381E* | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Mitsubishi | YS-11A-200, YS-11A-300, YS-11A-500, YS-11A-600 | N/A | 7639-27 | G-639ES | RG-390E | N/A | N/A |
| Mooney | M20, M20B, M20D, M20G, M20J, M20K | G-35 | N/A | N/A | RG-35, RG-35A, RG-35AXC | N/A | N/A |
| Mooney | M20J, M20K, M20L, M20M, M20R, M20S, M20TN | N/A | 7243-14 | N/A | RG24-16 | N/A | N/A |
| Aircraft OEM | Aircraft Model(s) | Gill Dry-Charged | Gill Sealed VRLA | Prev. Gill Part # | Concorde Equivalent | Air Tractor Equivalent | Marathon Equivalent |
| Mooney | M20, M20A, M20B, M20C, M20D, M20E, M20F, M20G, M20J, M20K | N/A | 7035-28 or 7035-34 | G-35S | RG-35, RG-35A, RG-35AXC | N/A | N/A |
| Mooney | M20J, M20K, M20L, M20M, M20R, M20S, M20TN | N/A | 7243-16 | G243S | RG24-16, RG24-17 | N/A | N/A |
| Mooney | M20J, M20K | N/A | 7242-14 | N/A | RG24-10, RG24-11, RG24-11M, RG24-15 | N/A | N/A |
| North American | AT6-C, AT6-D, AT6-F, T-6G, SNJ-5, SNJ-6, SNJ-7, or any BC-1A, AT6, AT6-A, AT6-B, SNJ-2, SNJ-3, SNJ-4 Converted; to 24 volts per North American Dwg. 121-954004. P-51 | GE-50E | N/A | N/A | N/A | N/A | N/A |
| Pilatus | PC-12 | G-6381E* | N/A | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Pilatus | PC-12, PC-12/45, PC-12/47, PC-47E Series | N/A | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Piper | PA-18, PA-18A, PA-18S, PA-18S-125, PA-18A-135, PA-18S-135,PA-18-150 | N/A | 7035-28 | G-35S | RG-35, RG-35A | N/A | N/A |
| Piper | PA-18A-150, PA-20, PA-20S, PA-20-115, PA-20S-115, PA-20-135, PA-20S-135, PA-22, PA-22-108, PA-22-135, PA-22S-135, PA-22-150, PA-22S-150, PA-22-160, PA-22S-160, PA-23, PA-23-160, PA-23-235, PA-23-250, PA-24, PA-24-250, PA-24-260, PA-24-400, PA-28-140, PA-28-150, PA-28-151, PA-28-160, PA-28-161, PA-28-180, PA-28-181 PA-28-201T, PA-28-235, PA-28-236, PA-28R-180, PA-28R-200, PA-28R-201, PA-28R-201T, PA-28RT-201, PA-28RT-201T, PA-30, PA-32-260, PA-32-300, PA-32R-300, PA-32-301, PA-32R-301, PA-32-301T, PA-32R-301T, PA-32RT-300, PA-32RT-300T, PA-34-200, PA-34-200T, PA-36-375, PA-39, PA-44-180, PA-44-180T | N/A | 7035-28 or 7035-34 | G-35S | RG-35, RG-35A, RG-35AXC | N/A | N/A |
| Piper | PA-11, PA-36, PA-38, Aerostar 600, 601, and 601P | G-25 | N/A | PS6-9 | RG-25, RG-25XC | N/A | N/A |
| Aircraft OEM | Aircraft Model(s) | Gill Dry-Charged | Gill Sealed VRLA | Prev. Gill Part # | Concorde Equivalent | Air Tractor Equivalent | Marathon Equivalent |
| Piper | PA-11, PA-12, PA-14, PA-16, PA-18, PA-22, PA-23, PA-24, PA-25, PA-28, PA-30, PA-32, PA-34, PA-39, PA-44 | G-35 | N/A | N/A | RG-35, RG-35A, RG-35AXC | N/A | N/A |
| Piper | PA-11, PA-22-108, PA-22-135, PA-22-150, PA-22-160, PA-23-235, PA-23-250, PA-28-140, PA-28-150, PA-28-151, PA-28-160, PA-28-161, PA-28-180, PA-28-181, PA-28-201T, PA-28-235, PA-28-236, PA-28R-180, PA-28R-200, PA-28RT-201, PA-28RT-201T, PA- 32-260, PA-32-300, PA-32R-300, PA-32RT-300, PA-32RT-300T, PA-36-285, PA-36-300, PA-36-375, PA-38-112 | N/A | 7025-20 or 7025-24 | G-25S | RG-25, RG-25XC | N/A | N/A |
| Piper | PA-23, PA-31 | G-246 | N/A | PS12-24P11 | RG24-20 | 7246-20AT, G-246AT | 27662-021, 29365-01C, 30135-001, 30135-002, 30450-001, 30554-01C, 32007-001, 32749-001, 32752-001, CA 103, CA 1700, CA 170A, M3-1700L, M3-170AL, SP 1700, SP 170A, SP 170AL, SP1700L |
| Piper | PA-23, PA-31, PA-36 | G-242 | N/A | G-242S, PS12-11 | RG24-10, RG24-11, RG24-11M, RG24-15 | N/A | N/A |
| Piper | PA-28-161, PA-28-181, PA-32-301FT, PA-32-301XTC, PA-32R-301 (HP), PA-32R-301(SP), PA-32R-301T, PA-46-310P, PA-46-350P | N/A | 7243-14 | N/A | RG24-16 | N/A | N/A |
| Piper | PA-31 | G-244 | N/A | PS12-24P9 | RG24-20 | 7246-20AT, G-246AT | 27662-021, 29365-01C, 30135-001, 30135-002, 30450-001, 30554-01C, 32007-001, 32749-001, 32752-001, CA 103, CA 1700, CA 170A, M3-1700L, M3-170AL, SP 1700, SP 170A, SP 170AL, SP1700L |
| Piper | PA-31P-350 | G-247 | N/A | N/A | RG24-20 | N/A | N/A |
| Piper | PA-46R-350T | N/A | 7243-16 | G-250S | RG24-16, RG24-17 | N/A | N/A |
| Piper | PA-31T, – 31T1, -31T2, PA-42, and PA-42-720 Series | 7000 Series by PMA | 7638-44* | N/A | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Aircraft OEM | Aircraft Model(s) | Gill Dry-Charged | Gill Sealed VRLA | Prev. Gill Part # | Concorde Equivalent | Air Tractor Equivalent | Marathon Equivalent |
| Piper | PA-31T, – 31T1, -31T2, PA-42, and PA-42-720 Series | G-6381E* | N/A | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Piper | PA-31, PA-31-300, PA-31-325, PA-31-350, PA-36-285, PA-36-300 | N/A | 7242-14 | N/A | RG24-10, RG24-11, RG24-11M, RG24-15 | N/A | N/A |
| Piper | PA-28-161, PA-28-181, PA-32-301FT, PA-32R-301(SP), PA-32R-301 (HP), PA-32R-301T, PA-32-310XTC, PA-46-350P |
N/A | 7243-16 | G243S | RG24-16, RG24-17 | N/A | N/A |
| Piper | PA-31, PA-31P, PA-31-300 | N/A | 7246-20 | N/A | RG24-20 | 7246-20AT, G-246AT | 27662-021, 29365-01C, 30135-001, 30135-002, 30450-001, 30554-01C, 32007-001, 32749-001, 32752-001, CA 103, CA 1700, CA 170A, M3-1700L, M3-170AL, SP 1700, SP 170A, SP 170AL, SP1700L |
| Piper | PA-23, PA-31 | G-246 | N/A | N/A | RG24-20 | 7246-20AT, G-246AT | 27662-021, 29365-01C, 30135-001, 30135-002, 30450-001, 30554-01C, 32007-001, 32749-001, 32752-001, CA 103, CA 1700, CA 170A, M3-1700L, M3-170AL, SP 1700, SP 170A, SP 170AL, SP1700L |
| Raytheon | MU-300-10, MU-300-400, MU-300-400T | G-6381E* | N/A | N/A | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Rockwell | 680T, 680V, 680W | G-6381E* | N/A | N/A | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Rockwell | 690, 690A | G-6381E* | N/A | BB638/T | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Rockwell | NA-265 Series | G-6381E* | N/A | BB638/T | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Aircraft OEM | Aircraft Model(s) | Gill Dry-Charged | Gill Sealed VRLA | Prev. Gill Part # | Concorde Equivalent | Air Tractor Equivalent | Marathon Equivalent |
| Rockwell | 680T, 680V, 680W | G-6381E* | N/A | BB638/T | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Sabreliner | NA-265, NA-265-20, -30, -40, -60, -65, -70, -80 | N/A | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Schweizer Aircraft Corp. | 269D | N/A | 7641-20 | G-641S | RG-206, RG-350, RG-355 | N/A | N/A |
| SIAI-Marchetti | F.260 | N/A | 7639-27 | G-639ES | RG-390E | N/A | N/A |
| Sikorsky | S-76A, S-76C | G-6381E* | N/A | N/A | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| Sikorsky | 269C, 269C-1 | N/A | 7243-14 | G-6381ES | RG24-16 | N/A | N/A |
| Sikorsky | S-76A, S-76B, S-76C | N/A | G-6381E | N/A | RG-380E/40, RG-380E/44 | N/A | N/A |
| Slingsby Aviation | T67M260, T67M260-T3A | G-243 | N/A | G-243S | RG24-16, RG24-17 | N/A | N/A |
| Socata | GA- 7 | N/A | 7025-20 or 7025-24 | N/A | RG-25, RG-25XC | N/A | N/A |
| Aircraft OEM | Aircraft Model(s) | Gill Dry-Charged | Gill Sealed VRLA | Prev. Gill Part # | Concorde Equivalent | Air Tractor Equivalent | Marathon Equivalent |
| Socata | TB9, TB10, TB20, TB21, TB200 | N/A | 7242-14 | N/A | RG24-10, RG24-11, RG24-11M, RG24-15 | N/A | N/A |
| Socata | TBM-700 | G-6381E* | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
| True Flight (Grumman) | AA-1, AA-1A, AA- 1B, AA-1C, AA-5, AA-5A, AA-5B | N/A | 7025-20 or 7025-24 | N/A | RG-25, RG-25XC | N/A | N/A |
| True Flight (Grumman) | AA-5, AA-5A, AA-5B, AG-5B | N/A | 7243-16 | G243S | RG24-16, RG24-17 | N/A | N/A |
| Twin Commander Aircraft | 680T, 680V, 680W, 690, 690A | N/A | 7638-44* | G-6381ES | RG-380E/40, RG-380E/44 | N/A | 20-S113, 24535-009, 24535-010, 27288-001, 27515-002, 27990-001, 29327-002, 29330, 29360-002, 29487-002, 29490-001, 30247-001, 30441-001, 30703-001, 30703-002, 31013-001, 31201-001, 31999-001, 32890-001, 38451-004, BTM 506, BTMA 5-20, BTSP 400, CA 16N, CA 176, CA 20H, CA 21H-1, CA 376, CA 400A, CA 5H, GSP 400, M3-44-15, MA 5, SP 276, SP 376L, STSP 400, TMA 5-20, TMA-5-20C |
* This battery requires an Elcon AC mating half connector to ensure proper fitment and connection.
** This battery has been discontinued. Please contact our team for more information.
The Bottom Line
When it’s time to replace your aircraft battery, trust Pilot John International® (PJi®) to keep you powered and flight-ready. We’re your go-to source for premium Gill aircraft batteries, including both dry-charged (flooded) and sealed valve-regulated lead-acid (VRLA) options – backed by FAA/PMA approval and built for lasting performance. Whether you're upgrading from another brand or following your OEM’s recommendation, we make it easy to find the right Gill battery for your aircraft.
In addition to Gill batteries, PJi offers everything you need to store, service, and maintain them – including battery acid (electrolyte), aircraft battery chargers, battery connectors, hydrometers, and sump jars. Our knowledgeable aviation support team is ready to assist you with expert guidance and fast answers. Contact us today by phone, email, or live chat to get the reliable battery solution your aircraft deserves.
