Aircraft Scales M2400-3-10CS – Wireless Weight Scales with Laptop, 30,000-lb. Capacity

The Aircraft Scales M2400-3-10CS is a complete wireless aircraft weighing kit that features three 10,000-lb. load cells, a wireless connection, and a laptop computer running Windows with Aircraft Scales software.

Wireless System Features

• Sealed, waterproofed wireless sensor network unit designed to integrate with load cells. Network capability allows several load cells to be active and used for different applications.
• IP65 NEMA4 enclosure measures 2.3" x 3" x 1.2" (59 x 76.6 x 30mm)
• A complete, battery-powered module running standard AA or C batteries provides up to 300 ft. in range
• Exceptionally low power for long battery life (up to 15 months tested on AA batteries)
• High Speed: 200 updates per second
• High Resolution: Up to 1 part in 400,000 (18 bit)
• Integral antenna supplied on the module; USB antenna supplied for laptop computer, PC, or tablet operation
• The high-accuracy, low-noise measurement delivers high-resolution, low-drift results that can be user-calibrated over 9 points to enable linearization and to deliver results in user-definable engineering units. The results can be transmitted at rates up to 200 per second to other devices such as handheld tablets, PCs, or the standard laptop computer supplied.
• The module is configured and calibrated (either by applying known inputs or by table entry) on a PC connected to the base station.
• The license-free 2.4 GHz direct sequence spread spectrum (DSSS) radio technology offers high integrity, error-free communications which can co-exist with other wireless technologies such as Wi-Fi, Bluetooth, and Zigbee. FCC, ETSI, and IC approvals.
