Nav-Aids ADA330-340-945 - Airbus A330/340 Pitot Static Adapters Kit (RVSM)

The Nav-Aids ADA330-340-945 is an air data accessories kit (RVSM) for the Airbus A330 / A340 (except 500 series).

The kit contains all the equipment required to test from the source the complete pitot and static air data system on the Airbus 330 & 340 aircraft, as well as the means of pre-testing all adaptors and hoses prior to being fitted to the aircraft.

Note:

This kit contains all the required adaptors for performing the pitot-static system test for Reduced Vertical Separation Minima (RVSM). This test requires the connection of all static test adaptors to static ports in each system (left and right fuselage). Please follow the A-330/340 Aircraft Maintenance Manual.

Included in this Kit

• Pitot Test Adaptor Part No. P75701-4 (3 req'd.)
• Pre-Test Adaptor Part No. PT17570 (3 req'd.)
• Static Test Adaptor Part No. S34093-4 (6 req'd.)
  • Please Note: These adaptors do not fit the stand-by static port on the A-340-500. The ADA330-340-946 kit is required.
• Pitot Test Hose Assembly Part No. 330-340-6360 (1 req'd.)
• Static Test Hose Assembly Part No. 330-340-7471 (1 req'd.)
• Seal Kit - Part No. SK701
• Seal - Part No. 084M1-229
• Manual Part No. 444-330-340-945
