JetPorter JP125S Towbarless Electric Aircraft Tug - Tow up to 125,000 lbs

JP125S Towbarless Electric Aircraft Tug
Tow up to 125,000 lbs

Benefits and Highlights of JP125S

• Ideal for long range corporate jets, regional aircraft, and military operations
• Dual Motors - Amazing ramp and hangar maneuverability and traction
• Independently excited
• We can reverse the inside wheel and speed up the outside wheel creating the best turning radius. Turning causes wing tip shift, and we virtually eliminated wingtip shift with our unit.
• Regenerative brakes - Creates a reduced and smoother deceleration and stopping distance.
• Industrial lead acid batteries configured for standard FBO 8hr shift
• Low maintenance, solid rubber tires
• Automatic activated and deactivated parking brake with LED indicator
• Waterproof cradle camera with 7” display for improved capture visibility (CAMERA IS AN OPTIONAL EXTRA ADD-ON)
• One year factory warranty from Tronair
• Unrivaled support and teamwork through our partnership with Tronair

Standard Features

• Sit down model
• Power steering
• Heavy duty long life torque hubs
• Regenerative motor braking on deceleration
• Programmed electric motor braking with brake pedal
• Automatic parking brake with LED indicator
• Controlled acceleration and deceleration foot operated throttle
• Two heavy duty 13 horsepower, continuous duty-cycle drive motors with microprocessor based controller - Creating more horsepower and superior control.
• Aircraft selection system to limit torque
• Oversteer (over-torque) protection system
• Proportional drive with steering position sensor
• Suspension system compensates for uneven ramp surface, dampens transmitted vibration for passengers, crew and operator
• Battery charge indicator with hourmeter
• 72 volt 440AH battery system
• Wheel tie down strap
• Nylon winch strap
• Nylon strut straps
• Winch system with safety switch
• Emergency safety cut off switch
• Hydraulic system filtration
• Solid rubber tires - 22 in front drive tires - 18 in rear steer tires
• Pintle hitch (rear)
• Fire extinguisher
• LED forward and rear facing lights
• Strobe light
• 4 LED marker lights
• Horn
• Finish: Durable Powder Coat Tronair Blue (Custom Colors Available on Request)

Battery Charger

• Single phase fully automated, multi-tap battery charger
• 50 HZ or 60 HZ - (indicate required frequency at time of quote)

Optional Equipment

• Weather proof camera and display
• Brake lights/turn signals
• Battery watering system
• Aircraft adapters
• Custom colors and graphics

Specifications

• Max Aircraft Weight - 125,000 lbs (56,699 kg)
• Cradle Capacity - 12,500 lbs (5,670 kg)
• Empty Speed - 7.5 mph (12 kph)
• Full Load Speed - 3 mph (4.8 kph)
• Length - 209 inches (530.9 cm)
• Width - 76 inches (193 cm)
• Height - 39 inches (98.4 cm)
• Weight - 9,500 lbs (4,309 kg)
