The Test Products International (TPI) 709 Combustion Analyzer is a state-of-the-art tool for optimizing combustion efficiency and reducing emissions in aviation applications. This advanced analyzer offers comprehensive measurement capabilities, including differential pressure, temperature, and flue gas analysis, providing valuable insights for improving aircraft engine performance and fuel economy.
Key Features
- Accurately measure CO, temperature differential, and calculate key combustion parameters such as CO2, CO Air Free, Excess Air, and Combustion Efficiency
- High-resolution differential manometer for precise pressure measurements, pump-driven operation for fast response, and built-in differential thermometer for comprehensive analysis
- Store up to 50 readings for trend analysis and troubleshooting
- Designed to withstand the rigors of aviation maintenance environments
- Intuitive interface and large, easy-to-read display for efficient operation
By providing comprehensive combustion data and analysis, the Test Products International (TPI) 709 Flue Gas Analyzer helps optimize engine performance, reduce fuel consumption, and minimize emissions, contributing to a safer and more sustainable aviation industry.
Standard Accessories Included
- Rubber Boot
- Soft Carrying Case
- Flue Sampling Probe
- In-Line Filter Assembly
- Temperature Probe
- Mini-Pump Protection Filter Assembly and Spare Filters
- Exhaust Spigot
- Instruction Manual
| General Information | |
|---|---|
| Part # | 709 |
| Manufacturer | Test Products International |
| Shipping Information | |
|---|---|
| Product Weight | 4.95 lbs. |
| Product Dimensions | 10 x 8 x 6 in. |
| Schedule B | 9027100000 |
| Specifications | |
|---|---|
| Accuracy | ±0/5% fsd |
| Battery Type | 1.5V AA (3) |
| Carbon Dioxide (CO2) Range | 0 to 25% |
| Carbon Dioxide (CO2) Resolution | 0.1% |
| Carbon Monoxide (CO) Accuracy | +/-5ppm or 5% of reading whichever is greater |
| Carbon Monoxide (CO) Range | 0 to 10,000 ppm |
| Carbon Monoxide (CO) Resolution | 1 ppm |
| CO/CO2 Range | 0 to 0.999 |
| CO/CO2 Resolution | 0.001 |
| Conformity | BS7927 (and the draft BS7967) |
| Data Logging | N/A |
| Data Storage | 50 Locations |
| Date and Time Function | 24 Hour Real Time Clock |
| Dimensions | 200mm x 90mm x 60mm |
| Display Type | Backlit 3 line LCD |
| Draft/PressureSelectable Ranges | mBar,kPa, and inH2O |
| Gross/Net Efficiency Range | 0 to 100% |
| Gross/Net Efficiency Resolution | 0.1% |
| Nitric Oxide Measurement | N/A |
| NOX Measurement | N/A |
| Operating Temperature | 14°F to 122°F (-10°C to 50°C) |
| Oxygen (02) Accuracy | ±0.3% |
| Oxygen (02) Range | 0 to 25% |
| Oxygen (02) Resolution | 0.1% |
| PC Communication | N/A |
| Print Capability | Yes, via optional IR printer (A740) |
| Ranges | -150 mBar to +150 mBar, -15 kPa to +15 kPa -60, inH2O to +60 in H20 |
| Resolution | 0.001 inH2O |
| Selectable Fuels | Natu |
Customers also viewed
AIRCRAFT COMPATIBILITY
This item is for use on all aircraft.
PRODUCT REVIEWS
This item does not have any reviews yet.
QUESTIONS & ANSWERS
If your analyzer is used in an oil fuel application, the A773 filter should be used. This filter does not have to be removed for other fuel types.
Gross efficiency is the correct choice for applications in the United States.
Yes, this analyzer can test for carbon monoxide in ambient air.
Yes! The TPI 709 combustion analyzer has a built-in differential manometer.
